PCBA Design for Manufacturing Analysis

• Verification of input files for CAM compatibility and generating reports on individual board characteristics against manufacturing specifications.
• Layer Analysis for annular ring, space & trace widths, Solder Mask, fiduciary openings & exposed traces.
• Silk Screen removal, scoring, V-cuts, routing, slot, route and retain, Test coupons
• Panelization or board array configuration with maximum usages.
• Gerber Translation/Reconstruction, Gerber-DXF, DXF editing & conversion
• Verification of Opens and Shorts, Matching of Drill data for accuracy
• Design for Test (DFT) analysis as per specific test fixture requirement.
• Design for manufacturing/Analysis (DFM) analysis and evaluation.

DFM, DFA, DFT Analysis Advantages

• Fewer revision spins per design.
• Fewer major production issues During manufacturing process.
• Avoid costly design changes and re-spins that delay project delivery
• Reduced time to market and increased on-time shipment commitments
• Reduced overall cost of test
• Use the right type of test depending on your process capability
• Align test strategy with defect opportunities.
• Reduced overall repair costs across process and product verification
• Process faults are detected earlier and with improved diagnostics
• Reduced PCB scrap and recycling costs
